Machine Tools 24-7 Machine Quote - Click on the Machine ID Number Below to View Machine Photos Separately

Below are the specs we have on file for this machine.  Please contact Machine Tools 24-7 if you have any questions.

Machine IDYearManufacturerModelControl
131551973TosSK-16

 DescriptionSpec Values
Capacity:Table Size / Table Load63" / 11,000 Lbs
 Maximum Swing Side Head Up / Side Head Down63" / 67"
 Height Under Rail50"
Spindle:Speeds Minimum - Maximum (12 speeds)3.5 - 150 RPM
 Motor30 HP
Heads:Number of Head(s)3 Heads
 Turret Head (power indexing)5 Position
 Ram Head1 Position
 Side Head4 Position
Travels:Turret Head Travel Vertical / Horizontal / Swivel25" / 40" / +/- 30°
 Ram Head Travel Vertical / Horizontal / Swivel R/L31.5" / 30" / 45°/35°
 Side Head Travel Vertical / Horizontal33" / 257"
Feeds:Standard Feed Range.002 - .035 IPR
 Rapid Traverse78 IPM
Dimensions:Floor Space (L x W x H) (depth is excluding drive motor)222" x 186" x 216"
 Weight (approx.)48,000 Lbs

 Equipped With
Additional Info.:63" 3-Jaw Chuck
 Ram Head Grinding Attachment
 DRO's


Click Here To Print Quote - 13155

Click Here To Email Quote Request - 13155

TERMS: Cash or Cashiers Check with order, and all equipment is FOB on floor from sold location unless otherwise stated. All equipment subject to prior sales and is exclusive of any government tax. Equipment descriptions are intended only as a guide and their accuracy is not guaranteed. CONDITIONS: Item(s) are sold "As Is, Where Is" unless other arrangements have been made and conveyed in writing. There are no warranties, which extend beyond the description on the face hereof; quotation subject to change without notice. All agreements and/or contracts made by sales person are subject to approval. -EQUIPMENT SAFETY: It is the buyer's/user's responsibility to provide proper safety devices and equipment to safeguard persons from harm resulting from any particular use, operation or set-up, and to adequately safeguard the equipment conform to all Federal, State and Local Government Safety Standards and all Industrial Standards. - INDEMNIFICATION: Buyer/User agrees to Indemnify and hold harmless Seller and Salespersons from any and all claims or liabilities caused by or arising from the equipment on the face hereof. All equipment quoted is subject to prior sale. It is purchasers responsibility to verify machine condition, specifications and pay any and all applicable taxes.




ManufacturerModelMachine IDMachine Photos
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16.jpg
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16 a.jpg
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16 b.jpg
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16 c.jpg
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16 d.jpg
TosSK-1613155http://www.machinetools247.com/images/machines/13155-Tos SK-16 e.jpg
